1.4T Oil-less Electric Press with Precision Pressure Controller for Ar Gas Glove-box - YLJ-1-4TA

1.4T Oil-less Electric Press with Precision Pressure Controller for Ar Gas Glove-box - YLJ-1-4TA

0.0/5 rating (0 votes)

Description

YLJ-1-4TA is an electric compressive press or jig with the digital pressure gauge and load cell up to max. 1400 kg force (1.4 metric Ton). It is designed for compressing small pellets ( 《1/4“ Dia. ) in glove-box for ceramic research and solid-state battery .
Note: Upgrade controller since July 2021

SPECIFICATIONS:
Power
  • NRTL & CSA certified 110 - 240V AC (50/60Hz) power adapter for universal use
  • 24V DC motor with reducing gear, 15W, which is suitable for using under Ar gas
Pressure
  • A built-in load cell with a digital display for pressure measurement and control
  • Pressure adjustment range: 10Kg - 1400Kg   ( 100N - 14000 N)
  • Pressure Accuracy: +/- 50N  ( 5Kg)
  • Pressing time:   2- 9999 min programmable
Working Space
  • Working plate:  φ40mm
  • Open height:    76mm
  • Max. Stroke: 40mm
Support Plate
3 stainless steel support plates are included:
  • 40mm Dia x 10mm H
  • 40mm Dia x 15mm H
  • 40mm Dia x 20mm H
Product Dimensions       220L x 130W x 430H  (mm)
Compliance
  • CE approval
  • NRTL or CSA (UL 1450) is available upon request at extra cost.
  • Note: NRTL certification is not necessary due to 24VDC safe device
Warranty One-year limited warranty with lifetime support (rusted and damaged parts due to improper storage condition or maintenance are not covered by warranty)
Application Notes
  • It can be used as a jig for compressing pressure adjustable split test cell, please click the picture in below for details:
  • It also can be used for pressing pellet via < 0.5" diameter die in the glove-box under both N2 and Ar gas
  • The press machine can be put into the glove-box through the air-lock chamber

Operation  Video         (Old version)       ( New version)
Net Weight 25 kg (55 lbs)
Shipping Weight 45 kg (100 lbs)
