100T Electric Hydraulic Press with Digital Display - YLJ-100E

100T Electric Hydraulic Press with Digital Display - YLJ-100E

3.0/5 rating (2 votes)


YLJ-100E is an electric hydraulic pressing machine up to 100 metric tons for preparing compound or ceramic samples faster and easier. YLJ-100E has a built-in electric hydraulic pump which is driven by an electric oil pump with a digital pressure display. It is an excellent tool for material/ceramic/chemistry laboratories to make a larger pellet sample.


  • Max. 100 Metric Tons ( 980 KN)
  • Digital pressure display (unit KN)
  • 10 - 100T adjusted by manual ON/OFF valve
  • Display real pressure on the sample based on die size
  • Pressure accuracy: +/- 1% by adjusting hydraulic oil valve
  • Max.  force (1030 KN, e.g 105T) release protection
  • The mini printer is built-in to calculate the pressure per sample area
Pressure Controller
  • Digital control panel to set up sample diameter and display real force.
  • The mini printer is built to displace real pressure
Electric Hydraulic Pump
Bottom Hydraulic Cylinder Travel Distance
  • 0 - 20 mm
  • Range sensing switch to prevent travel distance beyond 20 mm
Top Support Screw
  • 310 mm Max ( adjustable )
Working Space
  • Max opening: 250 L x 300 W x 300 H, mm
  • Diameter of top & bottom platform: 300 mm
Press Cover
  • A metal door with a magnetic door latch
  • Note: For safety, please close the door before operating
Net Weight & Dimension
  • Weight: 500 Kg
Shipping Dimensions
  • 48" L x 40" W  x 60" H
Weight of Shipment
  • 1280 lbs
Application Notes
  • Check the Oil Level Regularly. Add AW 46 Hydraulic Oil if the Oil Level is low
  • Do not raise the bottom cylinder (piston) more than it's maximum traveling distance (20 mm)
  • Warning: Customers must always wear protective goggles during operation !!!
  • Please shut the oil release valve and oil drain for transportation or long term idle
  • Operating the pressor inside the glove box is not recommended
  • CE Certified
  • NRTL (UL or CSA) Certification is available upon request at an extra cost  ( Isolation transformer will add on)
Pellet Press Dies (optional) &CIP die
  • Pressing dies with various diameters are available upon request at an extra cost (Pls click Pic 1 to order)
  • 32 hole die holder is available for high-throughput pressing ( Pi. 2)
  Pic. 1       Pic. 2

Operation Demo Video
  • The pressing machine was quality inspected in the USA, lifetime support is provided
  • One year limited standard warranty (Extended warranty is available up to 5 years at an extra cost)
