2" Polishing Fixture for Precision / Automatic Thinning w/o Vacuum - EQ-PF-2-1-LD

0.0/5 rating (0 votes)

Description

Features
  • Precision Polishing Jig for accurate wafer / substrate polishing and back-thinning
  • Sample holder can take wafer or substrate up to 2" Diameter with 2mm Max Thickness
  • Thickness control screw fixture with resolution of 0.005 mm to limit stock remove
  • Two micrometers are included with 0.001 mm increments
  • Two dead weights are included for adjusting polishing gravity
  • This Polishing fixture can fit with Unipol-810, Unipol-802 and any precision 8" polishing machine with yoke support to achieve automatic polishing or thinning.
  • Excellent for preparation of TEM sample and IC section analysis and Flat single crystal substrates
Dimension
  • Weight 6.95 lbs with both force weights.
  • Sample plate diameter: 2.125 inches
  • Diameter of the entire base: 90mm (~3.5 inches)
Product Image
  • Usually mounting a piece of sample on the surface of the bottom plate by wax.
  • It will fit another polisher if it came with the Y-sharp rack support.

  • Note: super-hard tungsten alloy is weld on the bottom of jig for polishing resistible.
