Automatic Roll to Roll Device for Any Rolling Machine - MSK-E2300RD

Name: Automatic Roll to Roll Device for Any Rolling Machine - MSK-E2300RD
Brand: Premier Solutions Pte. Ltd

0.0/5 rating (0 votes)

Description

MSK-E2300RD is an automatic Roll to Roll device designed to change any rolling machine into an automatic roll-to-roll rolling machine with a width <= 300mm. The reeling device is controlled by substrate tension force to match any rolling speed. An optical sensor is built in to rectify a deviation in width and achieve precision reeling.

SPECIFICATIONS:

Working Voltage	208 - 240 VAC, 50/60Hz, Single Phase 220V AC Power plug is not included (Please click here to order the plug) You may use a 500W transformer to operate at 110V
Max. Power Consumption	500W
Control Panel	7 " color touch screen control panel for adjusting tension force and deviation correction Reeling Tension force : 0 - 99N adjustable to match different speed levels
Reeling Width	<= 300 width for any material
Reeling/Unreeling Shaft	75mm O.D
Compliance	CE certified UL-ready component to ensure pass UL and CSA certification at extra cost
Warranty	One-year limited warranty with lifetime support Rusting and damage due to improper storage conditions or maintenance are not covered by a warranty
Application Notes	This roll-to-roll device is specially designed for MTI MSK-HRP-03 and MSK-E2300A it also can be used for any rolling machine as long as < 300mm, and plug the power of your rolling machine into the R2R device It is not allowed to use any MTI product in any hazardous location, especially prohibited from using in Class I environments (flammable gases & vapor).
Operation Video
Net Weight	300 kg
Shipping Weight & Dimensions	850 lbs 70"x45"x32"
