Power
| - 110 - 240V AC (50/60Hz) NRTL certified power adapter for worldwide use
- High torque 110VDC motor (70W Max.)
|
Power Cord Extention w/ Feed Through for using in a glove-box
| - An extension power cord with a feedthrough is included in the standard package. This extension is required for the following applications:
- No power source is available inside the glove box and the customer needs to extend the power cord to the outside of the glovebox,
|
Speed range | 0-600 rpm with digital display. |
Position Thickness & accuracy | - Cutting thickness is controlled by digital micrometer with the accuracy of 0.003mm
- The LCD micrometer is waterproof with a resolution of 0.001 mm and an accuracy of +/-0.003 mm.
- Thinnest cutting thickness is 0.35mm for most materials
-
|
Cutting Width | The cutting width of the slice is controllable from 1mm ~ 24mm by adjusting the LCD digital micrometer. |
Sample holder | Two angles adjustable sample holder is included, please click the picture below for the details http://www.mtixtl.com/images/products/thumb/SYJ150160sampleholder.jpg" alt="Sample holder" width="93" height="57" style="border: 1px solid black;" title="Click to enlarge" /> |
Mini-vise | Mini-vise is included, which can be easily adapted onto the sample holder to clamp rod shape specimens with a diameter up to 1'' max. |
Cutting Blades | - Max 6" diameter blade (it can also adapt 3" and 4" Dia. cutting blade)
- Max cutting depth is 50mm
- Three pcs total 6" cutting blades are included for cutting various materials:
- For heavy-duty cutting, please order an edge sintering blade as Optional
(optional)
- One plastic water-proof box is included to protect water from splashing during cutting
- Complete accessories are included (see standard list below)
|
Warranty & Compliance | - One year limited manufacturer warranty with lifetime support
- Rusting and damage due to improper storage conditions or maintenance are not covered by warranty
|
Certification | CE certified. With additional certification fees, MTI can arrange NRTL to perform UL/CSA inspection and label the machine per customer's request. |
Package dimension | 21" x 15" x 18" |
Accessory | Plexiglass protective shield |
Balance Weight | LSS002: 0.57 lbs LSS003: 0.52 lbs |
Shipping weight: | 40 lbs |
Dimension | |
Operation Video | |
Application Notes
| - Must use anti-corrosion coolant during cutting to avoid rusting the lead screw. Please never use water as a coolant during cutting. You may select our LubeCool-150 lubricant as a coolant which will make the diamond blade cut more efficiently and prevents corrosion. Also, you can use W10-30 motor oil as a coolant
- Always clean the machine, especially the lead screw by WD40 lubricant after each use
- Click here to learn how to mount/align the sample
- Applications on various materials
- Sing spacers to make gang saw, you may section multi-sample in one time (click pic left to learn how)
|
Warning | - It is required to use proper cutting fluid with the saw to prevent corrosion of the machine components. We strongly recommend you use an oil-based coolant or lube cool lubricant with the water. Do not use tap water directly, otherwise, the rusting component is not part of the warranty
- Never cut any materials without the use of proper cutting fluid. If you do so, serious damages can be caused by the spooler driving mechanism
- For cutting the sticky materials such as non-ferrous alloy, epoxy, and plastic, you must sharpen the diamond blade frequently. We suggest that cutting sample along with the included dressing stone (Glue sample and the dressing stone side by side and cut them together, this process will help keep the blade sharp enough for efficient cutting
- The saw can be used inside a glovebox with N2 gas, but no Ar gas
|
