FTC-2800 Multi-Channel Quartz Crystal Controller

The Lesker FTC-2800 deposition controller provides an economical way of doing sequential deposition. This affordably priced controller comes standard with (2) Sensor Inputs, (2) Source Outputs, (8) Digital I/O, RS-232 and USB Serial Ports, a bright 1/4VGA Active Matrix Color LCD Display. Included with each package is user friendly Windows^® Software, Power Cord, RS-232 Cable, I/O Connector and User's Manual.

• Bright, 1/4 VGA active matrix color LCD display – available in English or Chinese.
• Standard RS-232 and USB (with Ethernet option).
• Easy setup and operation with a "Quick Setup" Menu
• Windows^® program for developing, testing, and downloading processes, and for logging instrument data to your PC
• Accurate process control, especially for low deposition rates, with ±0.03 Hz resolution at 10 readings/second
• Storage capacity for up to 100 processes, 1,000 layers, 50 films.
• Monitoring of source material with a single sensor or with multiple sensors to provide accurate source distribution monitoring.
