FTM-2400 Multi-Channel Quartz Crystals Monitor

The Lesker FTM-2400 is an easy to use instrument for applications where manual control of the deposition process is adequate. This monitor comes standard with (2) Sensor Inputs, (2) Digital Inputs, (4) Relay Outputs, Analog Outputs for Rate & Thickness. Each package includes: User friendly Windows^® Software, Power Cord, RS-232 Cable, I/O Connector and User's Manual.

• 2 measurement channels standard, (additional 4 optional)
• Large, bright LED display
• Windows^® Software, easy to use, save process data in Excel^® format
• Analog outputs for rate/thickness recording
• High accuracy option: 0.03Hz at 10 readings/sec
• RS-232 standard, USB or Ethernet optional
• Two recorder outputs provide analog rate and thickness signals.
• User may press the Xtal Life button at any time to view the remaining crystal life.
• "Etch Mode" sets deposition rate negative for measuring etch rate
