HTR Series

Power supply suited for process heating up to 8kW.

Lesker M.A.P.S. HTR is a complete temperature controller and power supply for use with HV and UHV sample heaters, as well as other resistive heating elements. These units can provide manual output control, as well as programmable temperature control of ramp rate, presoak, and soak times via an integrated PID controller. This closedloop control can be initiated locally from the controller on the front panel of the supply, or remotely from a PC or PLC.

Features

• Microprocessor-based programmable temperature controller
• Microprocessor-based limit controller for over-temperature protection
• Controllers preprogrammed for Type-K thermocouple interface
• Type-K thermocouple input connectors
• Digital temperature, set point, and over-temperature readout
• Phase-angle fired SCR output
• Integrated current transducer
• RS-232 interface for remote PID control
• BNC connection for rate control
• Includes:
  • 10' Power Cord
  • 20' Inter Connect Cable (trim length to suit)
  • 20' Type K Thermocouple Wire (trim length to suit)
