KJLC® Regular Duty Exhaust Filters

Available in two series:

Compact Series Exhaust Filters

• Low-profile, compact open-body design with a high coalescing media
• Operates at 99.97% removal efficiency at 0.3 micron diameter particles with maximum inlet concentration of 500 ppmw (parts per million by wt.) mineral oil or 1,000 ppmw synthetic oil
• Filter has expanded metal on both sides of the media and nickel chrome construction with a plated finish
• Works between 4°C and 104°C

Pressure Release Series Exhaust Filters

• Feature a back pressure release valve with a 1/8" NPT oil drain to release the element at (7.38 psi) 0.5 bar differential for pump protection
• Fully drawn, sealed-body shell adds durability, making each filter nearly invulnerable to rust and vibration
• Compact, low-profile design uses high-performance coalescing media housed in a durable carbon steel construction with baked enamel finish
• Filters help purify the surrounding environment while giving a minimum efficiency of 99.7% on 0.3 micron diameter particles
• Operate at temperatures between 4°C and 104°C

NOTE: Element Included with Oil Mist Eliminators
