MKS PDR2000 Controller for Capacitance Manometers

0.0/5 rating (0 votes)



Lesker MKS PDR2000 Controller for Capacitance Manometers


A Kurt J. Lesker two-channel power supply/digital readout module for powering and displaying the MKS Baratron® family of transducers.


  • Unit can deliver up to 0.75 amps at ±15 VDC to operate up to two heated or unheated units
  • User can alternate readings via a select button on screen or view through an RS-232 interface when both units are simultaneously powered
  • Two-process relay trip points are available and may be assigned to either manometer
  • Upper and lower settings enable full control over the control trip point
  • Advanced power supply for 120–240 VAC power input
  • Engineering unit selection
  • Universal instrument for international applications
  • Mounted in a compact 1⁄8" DIN enclosure, weighing approximately 1 lb.
  • Can be used with one or two of these manometers: Type 626, 627, 629, 722, 750, 850, and 852



Lesker MKS PDR2000 Controller for Capacitance Manometers
