Features

| - Independent speed control for main disc revolution (0 - 400 RPM) and milling jar rotation (0 -1600 RPM) to allow the user to explore the best parameter for the wanted particle size and shape.
- Touch screen control panel for programming the speeds, the milling time, and the pause time.
- Four 500 mL stainless steel jars are included for immediate use.
- Other types of jars are available as an option.
- Note: Particle size is dependent on impact force and particle shape is dependent on shear force. It is the customer's responsibility to find the best parameter for various materials.
|
Working Voltage | |
Milling Speed & Centrifugal acceleration | - Main disc revolution: 10 - 400 RPM adjustable, Centrifugal acceleration: 16 g Max.
- Milling jar self-rotation: 50 - 1600 RPM adjustable Centrifugal acceleration: 120g
- Total Centrifugal acceleration: 136 g max.
|
Touch Screen Control
 | - Digital display and inputs for speed and time
- Up to 10 recipes can be stored
- Max. 5 segments speed control per recipe, up to 10 Cycles
- Rotation direction selectable, clockwise-anticlockwise
|
Material Feed Size | Crispy materials< 10mm (Others<3mm) |
Material Size for Input & Output | - Input size: < 3 mm Dia. for most materials and ~< 10 mm Dia. for brittle materials
- Output particle: Wet Milling < 1um average, Dry milling < 20um average
- Note:
- The output granularity is dependent on the material physical properties such as size, milling media and processing time. Minimum granularity can be as small as 0.1 um according to the customer's feedback.
|
Milling Jars

| - Four sets of 500 ml jars (Pic.1) with SS milling ball (Pic.2) combo are included.
- 1000 ml SS milling jars are available upon request at extra cost
- We provide a wide range of jar/ball materials for contamination-free processes, such as Nylon, Alumina, Zirconia, agate...Please contact us for more details.
- Hi-throughput milling tanks ( 8 x25 ml jars) are available upon request, which can mill 32 samples per batch.
 Pic.1  Pic. 2   Pic. 3 |
Noise Level | 55~70 decibel |
Holding Fixtures
 | - Four sets of holding fixtures are included
- Easy to tight for max. jar securing. Can hold jars with heights up to 80mm
|
Warranty | - One-year limited warranty with lifetime support
- Consumable parts, such as milling jar and grinding balls are not covered by the warranty
|
Compliance | - CE Certified
- NRTL certification is available at extra cost
|
Production Dimensions & Weight
 | - 530mmW×670mmL×1300mmH ( close cover )
- 530mmW×670mmL×1620mmH ( open cover )
- ~245kg
|
Operation Video |  |
Application Notes
 | - SS304 mixing jar is suitable for grinding various metal materials.
- In order to avoid contamination, please pre-milling the material 2-3 times before normally milling, which can make a coating on the surface of the jar and balls. Please use one jar for one type of material.
- For milling the oxide material, please choose alumina/Nylon jars and zirconia media. DO NOT USE stainless steel balls in Alumina jars.
- Must place 4 jars or 2 in symmetrical with similar weight in the ball mill to keep balance during rotation, If using one jar, you must put another jar with the same weight in a symmetrical position. Otherwise, unbalance rotation, especially one jar, may damage the machine.
- Please consider our SYU-3 Ultrasonic Filtration System for filtering the product
- Please click underline to learn Centrifugal Force calculation.
|
Shipping Weight | 800 lbs |
