Temperature Control Unit (PWM) with 30 Segments Programmable Optional 2- 5KW - EQ-MTC-C4

0.0/5 rating (0 votes)

WK518P temperature control unit is designed for precision control of high-temperature furnace from 500 - 1500 ^oC with heating elements of resistant wire or SiC.
Just connecting the power cord and thermocouple with the unit, you can run your furnace automatically.
The controller uses PID via SSR power control with 30 segments programmable.
Built in "auto tune" function allows you to adjust furnace temperature with minimum over-shooting.
Built in Protection to cut-off power for over-temperature.

Specifications:

Model	EQ-MTC-C4	EQ-MTC-C4-2000
Input & Output Voltage	Input 208 - 240 V AC single phase, 50/60 Hz for worldwide use Output 220V	Input power 110V AC / Output power 110V OR Input power 220V AC / Output power 220V
Max. Power	5000 W ( 25A )	2000 W
Thermo Couple Accepted	J, K, T, E, N, B, R, S,( thermo-couple is not included) J range: -310 to 1832 ^oF (-190 to 1000 ^oC) K range: -328 to 2502 ^oF (-200 to 1372 ^oC) T range: -328 to 752 ^oF (-200 to 400 ^oC) E range: -328 to 1832 ^oF (-200 to 1000 ^oC) N range: -328 to 2372 ^oF (-200 to 1300 ^oC) B range: 392 to 3272 ^oF (200 to 1800 ^oC) R range: 32 to 3214 ^oF (0 to 1768 ^oC) S range: 32 to 3214 ^oF (0 to 1768 ^oC) Please click picture below to order a thermal couple Thermal Couples (K, S, B type) & Calibration Kit
Temperature Control	The controller uses PID via SSR power control 30 segments programmable for heating rate, dwell temperature and time, and cooling rate Control accuracy +/-1.0 ^oC
Overall Dimension (mm)	360 x 340 x 190 mm ( L x D x H)	260 x 230 x 120 mm (L x D x H)
Back View
Weight (kg/lbs)	5 kg	3 Kg
Certificate	Met and CE recognized ( Controller alone )
Operation Instructions	Please click the link of How to use MTI furnace controller
Note	This temperature controller is designed for lab furnaces heated by resistant wire and SiC elements up to 1500^oC
